Ksrational Digital readoutWE6800-23
详细说明
Digital readout
WE6800
Usage
WE6800 series multi-functional digital readout can be installed on all kinds of lather machine tools, wihich
can supply the measuring location when used together with the linear scales.
Specialities
● Use our special 24-bit count chip, the reading speed can reach 5m per second
● Systematic anti-jamming in power and signal can reach 2200V or above
● Display data both in English and Chinses
● Can recall the current position (RI) after power failure
● Can work right between AC90V and 240V
Functions
● Coordinate zero reset, divide by 2, preset,ABS coordinate ,INC coordinate, 1000 groups of user coordinates
● Shrink rate, calculater
● De tect the RI
● Divide holes on a circle
● Divide holes on an oblige line
● Arc manufacturing, ramp manufacturing(WE-6800-2 WE-6800-3)
● EDM manufacturing(WE6800E)
● Edge detecting(option)
Model
WE6800-2
Two-axis digital readout
WE6800-3
Three-axis digital readout
WE6800-E
Appropriate to EDM only
WE6800-4
Four-axis digital readout
Specification
Voltage
AC90-240V
Power
The most is 15W
Dimension
295*185*45(mm)
Resolution(μm)
0.1、0.2、0.5、1、2、5、10、20
Linear scalesˋs signal
Orthogonality TTL , frequencyless than 2MHz , current more than 1 mA
Weight
1.45kg
