LargeStroke automatic image measuring instrument
详细说明
VMS-H LargeStroke automatic image measuring instrument
CNC video measuring machine
Large travel video measuring machine adopts air bearing and servo control technology. This video measuring machine can carry out mass measurement of accurate and high efficiency with this machine QIM5008 automatic measuring software. CNC video measuring machine is suitable for inspect and quality control of precision components. This video measring machine is used in mechanism, electronic, ironware, plastic. etc.
Specialities
● X, Y and Z axis were controlled by servo, with high positioning accuracy and smooth opration.
● The guides of X-axis and Y axis are made of granite with high-precision and possessed of steady performance and
not deform.
● This video measuring machine is easy to operate with jiystick
● Programmable and steady current cold lights surface lamps with four rings and four areas are suitable for
measuring various complicated work-pieces can carry out measurement for various complicated work-pieces.
● With laser pen, system can locate the measurement position quickly
Specification
Model –H
VMS-6060
VMS-6090
VMS-0810
VMS-1010
VMS-1012
VMS-1215
The travle of X-axis and Y-axis
600*900
900*900
800*1000
1000*1000
1000*1200
1200*1500
The glass table's size(mm)
1040*650
1050*920
1150*820
1110*1020
1310*1020
1220*1610
Dimension(m)
1.8*1.8*1.5
2.0*2.0*1.6
2.1*1.9*1.6
2.3*2.2*1.6
2.5*2.2*1.6
2.8*2.5*1.7
Weight(kg)
1700
2400
3260
3200
3750
4520
The travel of Z-axis
200mm
The travel of X-axis and Y-axis
300mm/s
Lens
America NAVITAR Mangnification 0.7X--4.5X
Light
Top light-LED surface ring light
Bottom light source-LED new type of linear lightThe resolution of linear scale
0.5μm
The indication error of X-axis and Y-axis
(4+L/200)μm(L is the length of the work pieces to be measured,unit:mm)
Camera
Imported color 1/2"CCD camera
Object view
11.1mm～1.7mm
